設備參數概述/Overview of equipment parameters |
軸移動量(X*Y*Z)/Displacement of axis (X*Y*Z) |
450mm*350mm*200mm |
主軸轉數/The spindle revolutions |
60000rpm |
數控系統/Numerical control system |
FAUC 3lI |
復位精度/Reset accuracy |
0.0001mm |
加工面型精度(PV)/Profile accuracy (PV) |
0.001mm |
加工表面粗糙度(Ra)/Machined surface roughness (Ra) |
10nm |
刀柄形式/The handle form |
HKS-E25含24刀庫/(contains 24 cutters) |
功能用途概述/Functional purpose overview |
油霧加工
Oil mist processing |
加工光學鎳鎢鋼鎳銅等表面光潔要求超高的光學產品(VR AR TV 激光 投影 車燈 醫療 手機鏡頭等)
Ultra-high optical products (VR AR TV laser projection car lamp medical phone lens, etc.) |
噴油加工
Injection processing |
加工各種尺寸要求超高的模具和機械產品(車仔,各種超高機器配件等)
Process all kinds of high - dimensional mold and machinery products(cars, various ultra-high machine accessories, etc.) |
